Product Information
-
Neo Drone
- Neo Intelligent Flight Battery x 3
- DJI Neo Two-Way Charging Hub
- Neo Propeller Guard
- Neo Propellers
-
Neo Spare Propeller Screw
-
Screwdriver
-
Neo Gimbal Protector
-
Type-C to Type-C PD Cable
-
Documents
-
Limited 1-Year Warranty
Performance | |
---|---|
Maximum Horizontal Speed | 13.42 mph (6 m/s) (Normal mode) 17.9 mph (8 m/s) (Sport mode) 35.79 mph (16 m/s) (Manual mode) |
Maximum Ascent Speed | 1.12 mph (0.5 m/s) (Cine mode) 4.47 mph (2 m/s) (Normal mode) 6.71 mph (3 m/s) (Sport mode) |
Maximum Descent Speed | 1.12 mph (0.5 m/s) (Cine mode) 4.47 mph (2 m/s) (Normal mode) 4.47 mph (2 m/s) (Sport mode) |
Maximum Takeoff Altitude | 6561’ / 2000 m |
Maximum Flight Time | 18 minutes (Each battery allows the drone to perform at least 20 palm takeoff and landing for shoots in succession) |
Max Flight Distance | 4.35 mi / 7 km |
Hovering Accuracy | Vertical: ±0.1 m (with vision positioning) ±0.5 m (with GNSS positioning) Horizontal: ±0.3 m (with vision positioning) ±1.5 m (with GNSS positioning) |
Max Wind Speed Resistance | 17.9 mph (8m/s) (Scale 4) |
Flight Control System | |
---|---|
Global Navigation Satellite System | GLONASS + GPS + Galileo + BeiDou |
Sensing System | |
---|---|
Downward | Precise Hovering Range: 0.5-10 m |
Operating Environment | Downward: Non-reflective, discernible surfaces with diffuse reflectivity of >20% (such as walls, trees, or people) Adequate lighting (lux > 15, normal indoor lighting conditions) |
Camera | |
---|---|
Sensor | 1/2-inch image sensor |
Effective Pixels | 12 MP |
Focal Length | 35mm Format Equivalent: 13mm |
Lens Field of View | 117.6º |
Aperture | f/2.8 |
Focusing Distance | 0.6m to ∞ |
ISO Range | Photo and Video: 100-6400 |
Photo Resolution | 4:3: 4000×3000 16:9: 4000×2256 |
Video Resolution | EIS Off: 4K (4:3): 3840×2880@30fps 1080p (4:3): 1440×1080@60/50/30fps EIS On: 4K (16:9): 3840×2160@30fps 1080p (16:9): 1920×1080@60/50/30fps |
Photo Format | JPEG |
Video Format | MP4 (H.264/MPEG-4 AVC) |
Digital Zoom | 2.7K: 3× FHD: 4× |
Color Mode | Normal |
Max Video Bitrate | 75 Mbps |
Recording Media | UHS-I Speed Class 3 or above is required |
QuickShots Modes | Dronie, Helix, Rocket, Circle, and Boomerang |
Gimbal | |
---|---|
Stabilization | Single-axis mechanical gimbal (tilt) |
Mechanical Range | Tilt: -120° to 120° |
Control Range | Tilt: -90° to 60° |
Max Control Speed (Tilt) | 100°/s |
Angular Vibration Range | ±0.01° |
Video Transmission | |
---|---|
Video Transmission System | DJI O4 |
Live View Quality | With DJI RC-N3 Remote Controller: Up to 1080p/30fps With DJI Goggles 3 plus DJI RC Motion 3/DJI FPV Remote Controller 3: Up to 1080p/60fps |
Operating Frequency | 2.400-2.4835 GHz 5.170-5.250 GHz 5.725-5.850 GHz Operating frequency allowed varies among countries and regions. Please refer to local laws and regulations for more information. |
Transmitter Power (EIRP) | 2.4 GHz: <26 dBm (FCC) < 20 dBm (CE/SRRC/MIC) 5.1 GHz: < 23 dBm (CE) 5.8 GHz: <26 dBm (FCC) < 14 dBm (CE) < 26 dBm (SRRC) |
Max Transmission Distance (unobstructed, free of interference) | FCC: 10 km CE: 6 km SRRC: 6 km MIC: 6 km The data was measured in an unobstructed outdoor environment free of interference and showed the farthest communication range for one-way, non-return flights under each standard. The maximum video transmission distance in the actual flight scenarios is limited by the drone's maximum flight distance. Always pay attention to RTH reminders on the live view during your flight. |
Max Transmission Distance (obstructed, with interference) | Low Interference and Obstructed by Buildings: Approx. 0-0.5 km Low Interference and Obstructed by Trees: approx. 0.5-3 km Data tested under FCC standard in environments with typical low interference. Used for reference purposes only and provides no guarantee for actual transmission distance. |
Lowest Latency | With DJI RC-N3 Remote Controller: Approx. 120 ms |
Neo Intelligent Flight Battery | |
---|---|
Battery Chemistry | Li-ion |
Capacity | 1435 mAh |
Energy | 10.5 Wh |
Nominal Voltage | 7.3 V |
Maximum Charging Voltage | 8.6 V |
Charging Temperature | 41 to 104°F / 5 to 40°C |
Weight | Approx. 1.59 oz / 45 g |
General | |
---|---|
Number of Rotors | 4 |
Operating Temperature | 32 to 104°F / 0 to 40°C |
Diagonal Size | 8.39" / 213 mm |
Overall Dimensions (L x W x H) | 5.12 x 6.18 x 1.91" / 130 × 157 × 48.5mm |
Takeoff Weight | Approx. 4.76 oz / 135 g |
Optional Battery Charging Hub | |
---|---|
Input | 5 V, 3 A 9 V, 3 A 12 V, 3 A 15 V, 3 A 20 V, 3 A |
Output | 5 V, 2 A |
Charging Type | Three batteries charged in simultaneously with ≥45W charger |
Optional RC-N3 Remote Controller | |
---|---|
Max Operating Time | Without Charging Any Mobile Device: 3.5 hours When Charging a Mobile Device: 1.5 hours |
Max Supported Mobile Device Size (Width x Thickness) | 3.4 x 0.4" / 86 x 10.2mm |
Connectivity | Lightning, Micro USB (Type-B), USB Type-C |
Battery Capacity | 2600 mAh |
Live View Quality | 720p/30fps |
Latency (depending on environmental conditions and mobile device) | Approx. 120 ms Depending on the actual environment and mobile device. |
Operating Temperature | 14 to 104°F / -10 to 40°C |
Weight | Approx. 0.71 lbs / 320 g |
Dimensions (L x W x H) | 4.1 x 5.91 x 1.78" / 104.2 × 150 × 45.2mm |
