Product Information
-
RODECaster Video All-in-One Production Console
-
2 x External Antenna
-
SuperSpeed USB-C to USB-C Cable
-
Power Supply
-
Limited 1-Year Warranty (Extendable to 2-Years)
Video | |
---|---|
Video Input Feeds | 6 simultaneous |
HDMI Inputs | 4x type-A (HDMI 1.4b) |
USB (UVC) Inputs | 2 multi-function USB-C for UVC video |
HDMI Outputs | 2 configurable – preview, program, multiview |
Video Input Frame Rates | 1920x1080p: 23.97, 24, 25, 29.97, 30, 50, 59.94, 60 (HDMI only) 1920x1080i: 25, 29.97, 30 |
Video Output Frame Rates | 1920x1080p: 24, 25, 30, 50, 60 |
Video Streaming Standards | 1920x1080p: 23.97, 24, 25, 29.97, 30, 50, 59.94, 60 |
Video Engine Colour Space / Bit Depth | 4:4:4 RGB / 8-bit |
HDMI Input Colour Space / Bit Depth | 4:4:4 RGB, 4:4:4 YUV, 4:2:2 YUV / 8, 10, 12-bit |
HDMI Output Colour Space / Bit Depth | 4:4:4 RGB, 4:4:4 YUV / 8-bit |
USB Input Colour Space | 4:2:2 YUV, 4:2:0 YUV (NV12) |
USB Output Colour Space / Bit Depth | 4:2:2 YUV / 8-bit |
Format and Frame Rate Converters | On all HDMI and USB inputs |
Streaming, Recording and Software | |
---|---|
Direct Streaming | Real Time Messaging Protocol (RTMP/RTMP) over Ethernet or Wi-Fi |
Supported Platforms | Youtube Live Twitch Live Facebook Live Twitter/X Live Custom server |
Network | Ethernet (10/100/1000 BaseT) and Wi-Fi 6 (2.4 and 5GHz) for streaming, configuration, remote control with computer and over-theair updates |
Storage Media | External USB mass storage device (exFAT format) for recordings |
Video Recording | Program feed as H.264/AVC MP4 file with embedded AAC stereo mix |
Isolated (ISO) Video Recording | 6 video inputs and 1 Program feed as independent H.264/AVC files (up to 1080p30) |
Audio Recording | Stereo mix WAV audio file |
Multitrack Audio Recording | 9 independent stereo WAV audio files |
RØDE Central Companion Software | Scene builder: advanced construction of scenes and remote control of device Auto-switching: configuration of automatic switching based on audio input Audio mixer: advanced configuration and control of audio sources, processing and routing Stream profiles: configuration for streaming settings and profiles Device configuration: advanced settings and customizations |
Compatible Operating Systems | macOS 10.15 or later Windows 10 Version 1803 or later Windows 11 |
Audio | |
---|---|
Analog Audio Inputs | 2 combo jacks (microphone, line or instrument) with Revolution Preamps™ |
Wireless Audio Inputs | 2 Series IV wireless receivers |
Digital Audio Inputs | USB 1: 2-in/2-out or multichannel (20-in) output USB 1 Chat (uses USB 1 port): 2-in/2-out with mix-minus USB 2: 2-in/2-out with MFi support USB 4 & 5: compatible with RØDE USB microphones and RØDECaster Pro II and Duo |
Analog Audio Outputs | 2 headphone outputs (1/4-inch) 2 balanced line outputs (1/4-inch, L/R) |
Audio Mixer | 20 possible audio sources (9 stereo channels simultaneously): combo 1 and 2 (can be combined for stereo), wireless 1 and 2, video clips, sounds, HDMI 1, 2, 3 and 4 (each can be split for two mono), Bluetooth,3 USB audio interfaces (computers), 2 hosting USB audio devices (microphones) 12 Outputs with Custom Routing: live mix, headphone 1, headphone 2, recording, monitors, USB Main, USB Chat, USB 1, 2, 4 and 5, Bluetooth Note: Each output can be independently configured with custom level, mute status and level offset settings for each of the 9 inputs |
Audio Processing | APHEX® VoxLab™ Processing: per channel Advanced APHEX® granular processing on each channel: Compressor, Equaliser (EQ), De-esser, Panning, Noise Gate, High-pass Filter, Aural Exciter™, Big Bottom™ |
Preamps | Frequency range: 20Hz – 20kHz Input gain: up to 76dB Input Equivalent Input Noise: -131.5dBV (A-weighted) |
Switching | |
---|---|
Total Number of Layers | 9 simultaneous in Preview and Program |
Downstream Keyers | 2 (overlays and logo) |
Chroma Keyers (Green and Blue) | 2 |
Media Players | 2 simultaneous |
Transitions | SMPTE wipes, dip and fade |
True Preview | Display complete scenes and overlays simultaneously in preview and program |
Generated Borders | All scenes |
Multi-view | Program and preview Live inputs, scene and media thumbnails Audio mixer and channel status Recording, network and storage status Run time, date and time information |
Media Player | Expandable microSD card storage Videos: MP4 Images: PNG, JPG Audio: WAV |
Bluetooth | 5.3 (for stereo audio input or phone calls) |
General | |
---|---|
Dimensions | 12 x 5.2 x 2.4" / 305.9 x 132 x 61.4mm |
Weight | 2.8 lb / 1257g |
Power Supply Requirements | USB-C PD 60W, 20V 3A |
