48 MP
1/1.3" CMOS Sensor
100-12800
ISO Range
HDR 4K60/4K100
Video
34 Mins
Max Flight Time
35.8 mph
Max Speed
- 4K60 HDR video and 48MP RAW photos
- Tri-Directional Obstacle Sensing
- True Vertical Shooting for Online Content
- Focus Tracking and MasterShots
- Weighs Less than 249 g
- MasterShots and Timelapse
Description
Aircraft Performance | |
---|---|
Maximum Horizontal Speed | 35.79 mph / 16 m/s (S Mode) 22.37 mph / 10 m/s (N Mode) 13.42 mph / 6 m/s (C Mode) |
Maximum Ascent Speed | 11.18 mph / 5 m/s (S Mode) 6.71 mph / 3 m/s (N Mode) 4.47 mph / 2 m/s (C Mode) |
Maximum Descent Speed | 11.18 mph / 5 m/s (S Mode) 6.71 mph / 3 m/s (N Mode) 3.36 mph / 1.5 m/s (C Mode) |
Flight Ceiling Above Sea Level | With Intelligent Flight Battery: 4000 m With Intelligent Flight Battery Plus: 3000 m |
Maximum Flight Time (no wind) | 34 mins (with Intelligent Flight Battery and measured while flying at 21.6 kph in windless conditions) 47 mins (with Intelligent Flight Battery Plus and measured while flying at 21.6 kph in windless conditions). |
Maximum Hover Time (no wind) | 30 mins (with Intelligent Flight Battery, no wind) 40 mins (with Intelligent Flight Battery Plus, no wind) |
Max Flight Distance (no wind) | 18 km (with Intelligent Flight Battery and measured while flying at 43.2 kph in windless conditions) 25 km (with Intelligent Flight Battery Plus and measured while flying at 43.2 kph in windless conditions) |
Maximum Tilt Angle | 25° (C mode) 30° (N mode) 35° (S mode) |
Hovering Accuracy | Vertical: ± 0.1 m (with vision positioning) ± 0.5 m (with GNSS positioning) Horizontal: ± 0.3 m (with vision positioning) ± 0.5 m (with High-Precision Positioning System) |
Maximum Angular Velocity | 130°/s (S Mode) *Can be adjusted between 20°/s and 250°/s in the app 75°/s (N Mode) *Can be adjusted between 20°/s and 120°/s in the app 30°/s (C Mode) *Can be adjusted between 20°/s and 60°/s in the app |
Max Wind Speed Resistance | 23.94 mph / 10.7 m/s (Level 5) |
Camera | |
---|---|
Sensor | 1/1.3-inch CMOS |
Effective Pixels | 48 MP |
Lens | FOV: 82.1° Format Equivalent: 24mm Aperture: f/1.7 Focus: 1 m to ∞ (with autofocus) |
ISO Range | Video Normal and Slow Motion: 100-6400 (Normal) 100-1600 (D-Log M) 100-1600 (HLG) Night: 100-12800 (Normal) Photo 12 MP: 100-6400 48 MP: 100-3200 |
Max Image Size | 8064×6048 |
Photo Format | JPEG, DNG (RAW) |
Still Photography Modes | Single Shot: 12 MP and 48 MP Burst Shooting: 12 MP, 3/5/7 frames 48 MP, 3 frames Automatic Exposure Bracketing (AEB): 12 MP, 3/5/7 frames at 0.7 EV step 48 MP, 3 frames at 0.7 EV step Timed: 12 MP, 2/3/5/7/10/15/20/30/60 s 48 MP, 5/7/10/15/20/30/60 s |
Shutter Speed | 12MP Photo: 1/16000-2 s (2.5-8 s for simulated long exposure) 48MP Photo: 1/8000-2 s |
Video Resolution | 4K (3840×2160): 24/25/30/48/50/60/100fps FHD (1920×1080): 24/25/30/48/50/60/100/200fps |
Video Format | MP4/MOV (H.264/H.265) |
Zoom Range | 12MP Photo: 1-2x 4K: 1-3x 2.7K: 3x FHD: 1-4x |
Max Video Bitrate | 150 Mbps |
Supported File Formats | exFAT |
Video Formats | MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265) |
QuickShot Modes | Dronie, Helix, Rocket, Circle, Boomerang, and Asteroid |
Color Profiles | Normal D-Cinelike |
Supported File System | FAT32 (≤32 GB) exFAT (>32 GB) |
Supported Memory Cards | UHS-I Speed Class 3 or above is required. A list of recommended microSD cards can be found below. |
Recommended microSD Cards | SanDisk Extreme 64GB V30 A1 microSDXC SanDisk Extreme 128GB V30 A2 microSDXC SanDisk Extreme 256GB V30 A2 microSDXC SanDisk Extreme 512GB V30 A2 microSDXC Lexar 1066x 64GB V30 A2 microSDXC Lexar 1066x 128GB V30 A2 microSDXC Lexar 1066x 256GB V30 A2 microSDXC |
Internal Storage | 2 GB |
Flight Control System | |
---|---|
GNSS Support | GPS + Galileo + BeiDou |
Gimbal | |
---|---|
Stabilization | 3-Axis (tilt, roll, pan) |
Mechanical Range | Tilt: -135 to 80° Roll: -135 to 45° Pan: -30 to 30° |
Controllable Range | Tilt: -90° to 60° Roll: -90° to 0° |
Max Controllable Speed (tilt) | 100°/s |
Angular Vibration Range | ±0.01° |
Sensing System | |
---|---|
Forward | Precision Measurement Range: 0.39-25 m Effective Sensing Speed: Flight speed <10 m/s FOV: Horizontal 106°, Vertical 90° |
Backward | Precision Measurement Range: 0.36-23.4 m Effective Sensing Speed: Flight speed <10 m/s FOV: Horizontal 58°, Vertical 73° |
Downward | Precision Measurement Range: 0.15-9 m Precise Hovering Range: 0.5-12 m Vision Sensor Hovering Range: 0.5-30 m Effective Sensing Speed: Flight speed <3 m/s FOV: Forward/Backward 104.8°, Left/Right 87.6° |
Auxiliary Bottom Light | N/A |
Operating Environment | Diffuse reflective surface with a clear pattern and reflectivity >20% (such as cement pavement) Adequate lighting (lux >15, e.g. , normal exposure environment with indoor fluorescent lamp) |
3D Infrared Sensor | Measurement Range: 0.1-8 m (reflectivity > 10%) FOV: Front and Back 60°, Left and Right 60° |
Video Transmission | |
---|---|
Video Transmission System | DJI O4 |
Live View Quality | Up to 1080p@60fps |
Operating Frequency | 2.400-2.4835 GHz 5.170-5.250 GHz 5.725-5.850 GHz |
Transmitter Power (EIRP) | 2.4 GHz: < 33 dBm (FCC) < 20 dBm (CE/SRRC/MIC) 5.1 GHz: < 23 dBm (CE) 5.8 GHz: < 33 dBm (FCC) < 30 dBm (SRRC) < 14 dBm (CE) |
Communication Bandwidth | 1.4MHz/3MHz/10MHz/20MHz/40MHz |
Latency (depending on environmental conditions and mobile device) | Aircraft + Remote Controller: Approx. 120 ms |
Max Video Bitrate | Aircraft + Remote Controller: 18 Mbps |
Max Download Bitrate | O4: 10 MB/s (with DJI RC-N2) 10 MB/s (with DJI RC 2) Wi-Fi 5: 30 MB/s* |
Max Transmission Distance (unobstructed, free of interference) | FCC: 20 km CE: 10 km SRRC: 10 km MIC: 10 km |
Max Transmission Distance (obstructed, with interference) | Low Interference and Obstructed by Buildings: approx. 0-0.5 km Low Interference and Obstructed by Trees: approx. 0.5-3 km |
Max Transmission Distance (unobstructed, with interference) | Strong Interference: urban landscape, approx. 1.5-4 km Medium Interference: suburban landscape, approx. 4-10 km Low Interference: suburb/seaside, approx. 10-20 km |
Antennas | 4 antennas, 1T2R |
Wi-Fi and Bluetooth | |
---|---|
Wi-Fi Protocol | 802.11 a/b/g/n/ac |
Wi-Fi Transmitter Power (EIRP) | 2.400-2.4835 GHz: <19 dBm (FCC/CE/SRRC/MIC) 5.725-5.850 GHz: <20 dBm (FCC/SRRC), <14 dBm (CE) |
Bluetooth Protocol | Bluetooth 5.2 |
Bluetooth Transmitter Power (EIRP) | 2.400-2.4835 GHz: <8 dBm |
Intelligent Flight Battery | |
---|---|
Capacity | 2590 mAh |
Weight | Approx. 2.75 oz / 77.9 g |
Voltage | 7.32 V |
Charging Voltage Limit | 8.6 V |
Battery Type | Li-ion |
Energy | 18.96 Wh |
Charging Time | 70 minutes (with the DJI 30W USB-C Charger and the battery mounted to the aircraft) |
Charging Temperature | 41 to 104°F / 5 to 40°C |
Recommended Charger | DJI 30W USB-C Charger or other USB Power Delivery chargers |
Intelligent Flight Battery Plus | |
---|---|
Capacity | 3850 mAh |
Weight | Approx. 4.27 oz / 121 g |
Voltage | 7.38 V |
Charging Voltage Limit | 8.5 V |
Battery Type | Li-ion |
Energy | 28.4 Wh |
Energy | 28.4 W |
Charging Time | 101 minutes (with the DJI 30W USB-C Charger and the battery mounted to the aircraft) |
Charging Temperature Range | 41 to 104°F / 5 to 40°C |
Recommended Charger | DJI 30W USB-C Charger or other USB Power Delivery chargers |
Charging Hub | |
---|---|
Charge Time | Intelligent Flight Battery: 58 minutes (with the DJI 30W USB-C Charger and the battery inserted into the Two-Way Charging Hub) Intelligent Flight Battery Plus*: 78 minutes (with the DJI 30W USB-C Charger and the battery inserted into the Two-Way Charging Hub) |
Compatible DJI Charger | DJI 30W USB-C Charger or other USB Power Delivery chargers |
Compatible DJI Batteries | DJI Mini 4 Pro Intelligent Flight Battery, DJI Mini 3 Series Intelligent Flight Battery/Intelligent Flight Battery Plus |
Input | 5 V, 3 A 9 V, 3 A 12 V, 3 A |
Output (USB) | Max Voltage: 5 V, Max Current: 2 A |
Charging Type | Three batteries being charged in sequence |
DJ RC-N2 Remote Controller | |
---|---|
Max Supported Mobile Device Size | 180×86×10 mm (L×W×H) |
Transmitter Power (EIRP) | 2.4 GHz: < 33 dBm (FCC) < 20 dBm (CE/SRRC/MIC) 5.1 GHz: < 23 dBm (CE) 5.8 GHz: < 33 dBm (FCC) < 14 dBm (CE) < 30 dBm (SRRC) |
Max Battery Life | Max Operating Time Without charging any mobile device: 6 hours When charging a mobile device: 3.5 hours |
Operating Temperature | -10° to 40° C (14° to 104° F) |
Charging Time | 2.5 hours |
General | |
---|---|
Number of Rotors | 4 |
Operating Temperature | 14 to 104°F / -10 to 40°C |
Diagonal Size | 9.72" / 247mm |
Overall Dimensions | Folded Without Propellers: 5.83 x 3.7 x 2.52" / 148 × 94 × 64mm Unfolded With Propellers: 11.73 x 14.69 x 3.98" / 298 × 373 × 101mm |
Takeoff Weight | 8.78 oz / <249 g |
